Graco Paint Spray Equipment
EDGE II Gun with Metal Cup Part Number 17P653
- SKU:
- 17P653
- MPN:
- 17P481
- Availability:
- Usually Ships in 24 Hours. Item may ship direct from factory. EAH will contact you by phone or email with details.
- Weight:
- 2.00 LBS
- Width:
- 13.00 (in)
- Height:
- 6.00 (in)
- Depth:
- 9.00 (in)
Frequently bought together:
Description
HVLP • EDGE II Series • Fine Finish Guns
Compare the 4 Graco EDGE II / EDGE II PLUS Guns
Same family, two control styles, and two cup options. Use this chart to pick the exact gun that fits your workflow.
Current Part # on this page: 17P653
| Feature | EDGE II Metal Cup 17P653 Current |
EDGE II FlexLiner 17P481 |
EDGE II PLUS FlexLiner 17P483 |
EDGE II PLUS Metal Cup 17P484 |
|---|---|---|---|---|
| Series | EDGE II | EDGE II | EDGE II PLUS | EDGE II PLUS |
| Cup System | 1 qt Metal Cup | 1 qt FlexLiner Cup | 1 qt FlexLiner Cup | 1 qt Metal Cup |
| Control Style | Integrated flow control (material + air together) | Integrated flow control (material + air together) | Independent controls (material / air / fan size) | Independent controls (material / air / fan size) |
| Max Air Pressure | 10 psi | 10 psi | 10 psi | 10 psi |
| Max Fluid Pressure | 50 psi | 50 psi | 50 psi | 50 psi |
| Spray Patterns | Horizontal Vertical Round | Horizontal Vertical Round | Horizontal Vertical Round | Horizontal Vertical Round |
| Quick Take | Simplest to run. Metal cup configuration. | Simplest to run. FlexLiner configuration. | Most adjustable. Independent controls. | Most adjustable. Independent controls. |
Warranty Information
Graco Standard Warranty Graco Standard Warranty Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or maintenance of structures, accessories, equipment or materials not supplied by Graco. This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation. THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale. GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are subject to the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for breach of these warranties. In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the negligence of Graco, or otherwise.
