Name: Graco HVLP EDGE II Plus EDGE II Plus Gun with Metal Cup Part 17P484
Brand: Graco Paint Spray Equipment
SKU: 17P481
Availability: OutOfStock

Graco HVLP EDGE II Plus EDGE II Plus Gun with Metal Cup Part 17P484

(No reviews yet) Write a Review

SKU:

17P481

MPN:

17P481

Availability:

Usually Ships in 24 Hours. Item may ship direct from factory. EAH will contact you by phone or email with details.

Weight:

2.00 LBS

Width:

13.00 (in)

Height:

6.00 (in)

Depth:

9.00 (in)

Description
Warranty Information
0 Reviews

Description

HVLP • EDGE II Series • Fine Finish Guns

Compare the 4 Graco EDGE II / EDGE II PLUS Guns

Same family, two control styles, and two cup options. Use this chart to pick the exact gun that fits your workflow.

Current Part # on this page: 17P481

Feature	EDGE II FlexLiner 17P481 Current	EDGE II Metal Cup 17P653	EDGE II PLUS FlexLiner 17P483	EDGE II PLUS Metal Cup 17P484
Series	EDGE II	EDGE II	EDGE II PLUS	EDGE II PLUS
Cup / Feed System	1 qt FlexLiner Cup (bag system)	1 qt Metal Cup	1 qt FlexLiner Cup (bag system)	1 qt Metal Cup
Control Style (Big Difference)	Integrated flow control (material + air together) Quick adjustment with 360° rotation indicator.	Integrated flow control (material + air together) Quick adjustment with 360° rotation indicator.	Ultimate control (independent controls) Independent fluid & air controls + additional pattern size control.	Ultimate control (independent controls) Independent fluid & air controls + additional pattern size control.
Includes	1 qt FlexLiner Cup + #3 Quick Release Fluid Set	1 qt (0.95 L) Metal Cup + #3 Quick Release Fluid Set	1 qt FlexLiner Cup + #3 Quick Release Fluid Set	1 qt (0.95 L) Metal Cup + #3 Quick Release Fluid Set
Max Air Pressure	10 psi	10 psi	10 psi	10 psi
Max Air Inlet Pressure	10 psi	13 psi	11 psi	12 psi
Max Fluid Pressure	50 psi	50 psi	50 psi	50 psi
Gun Weight	20 oz	20 oz	20 oz	20 oz
Spray Patterns	Adjustable air cap (3-position): Horizontal Vertical Round	Adjustable air cap (3-position): Horizontal Vertical Round	Adjustable air cap + PLUS pattern control: Horizontal Vertical Round PLUS adds pattern size control for faster changes.	Adjustable air cap + PLUS pattern control: Horizontal Vertical Round PLUS adds pattern size control for faster changes.
Compatible Materials	Varnish, Enamel, Latex, Stains	Varnish, Enamel, Latex, Stains	Varnish, Enamel, Latex, Stains	Varnish, Enamel, Latex, Stains
Quick Take	Simplest to run. Great if you want one dial to “set & spray.”	Simplest to run + metal cup preference.	Most adjustable. Best when you want to dial air/fluid/fan independently.	Most adjustable + metal cup preference.

Sources: Graco product specs for 17P481, 17P653, 17P483, 17P484, plus Graco EDGE II brochure/manual describing EDGE II vs EDGE II PLUS control differences.

Not Sure Which EDGE II Gun Is Right For You?

The EDGE II and EDGE II PLUS spray guns offer different control layouts depending on the coatings you plan to spray and the level of adjustment required. Choosing the correct configuration can reduce material thinning, improve atomization, and shorten job time in the field.

? Tap to Call Technical Support: 210.822.9393

To help us recommend the best spray gun for your application, please have the following ready:

Material or coating type (urethane, epoxy, latex, etc.)
Solids content or viscosity (if known)
Surface or substrate being coated
Desired finish quality
Turbine model or spray system you are using

EAH Industrial supports over 3,000 refinishing professionals and can help match your spray gun configuration to your coatings and turbine system.

For complete factory specifications: Download the EDGE II Series Brochure (PDF)

View AllClose

Warranty Information

Graco warrants all equipment, which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations.
